JUKI MO-6804AS-0A4-150/DD10K – 3-Thread Industrial Rolled Hem Overlock Machine

JUKI Japan · Industrial Sewing Equipment

Precision Rolled Hem Finishing for Lightweight Fabrics

The JUKI MO-6804AS-0A4-150/DD10K is a specialised 1-needle, 3-thread industrial overlock machine configured for narrow rolled hem applications. It is designed for professional sewing environments that require fine edge finishing on suitable lightweight and extra-lightweight materials.

Featuring a DD10 direct-drive servo motor and JUKI Semi-Dry Head technology, the listed configuration is designed to support responsive operation and help reduce the risk of oil contamination around critical sewing areas. It is suitable for applications such as scarves, lightweight fashion garments and selected bridal textiles, subject to fabric testing and correct machine setup.

1 Needle · 3 Threads Specialised industrial overlock configuration. 1.5 mm Overedge Width Specified narrow rolled hem configuration. Up to 7,000 sti/min Maximum speed stated in the supplied specifications. DD10 Direct Drive Integrated motor configuration for responsive industrial operation.

Key Features of the JUKI MO-6804AS

01

Narrow Rolled Hem Finishing

The specified 1.5 mm overedge configuration is intended for fine rolled hems with minimal bulk on suitable lightweight materials.

 02

Semi-Dry Head Technology

Designed to help reduce oil contamination around selected sewing areas, helping protect delicate fabrics from oil staining.

 03

DD10 Direct-Drive Servo

The integrated direct-drive motor supports responsive operation. Actual noise, vibration and energy consumption depend on setup and working conditions.

 04

High-Speed Production

The supplied specifications state a maximum speed of up to 7,000 stitches per minute. Practical production speed depends on the fabric, operator and application.

 05

Differential Feed Adjustment

Helps control fabric feeding and manage stretching, puckering or gathering when correctly adjusted for the material.

 06

Industrial Construction

Designed for professional sewing operations where consistent edge finishing, routine maintenance and dependable performance are important.

Ideal Applications

This rolled hem configuration is intended for fine edge finishing on compatible lightweight materials. Always test the intended fabric and thread combination before production.

Fashion & Bridal

  • Bridal veils and selected bridal textiles
  • Lightweight fashion garments
  • Scarves and decorative fabric edges
  • Chiffon and organza
  • Selected silk fabrics

Specialised Apparel

  • Lightweight blouses and shirts
  • Selected lingerie applications
  • Children's lightweight garments
  • Fine woven fabrics
  • Selected delicate textile products

Fabric suitability: This is a specialised narrow rolled hem machine, not a universal overlocker for every fabric weight. Heavy denim, thick multilayer materials and many heavier sportswear applications may require a different machine configuration. Please discuss your material and intended seam with our team.

Why Choose the MO-6804AS?

  • Produces a fine rolled hem on suitable lightweight materials.
  • Helps create neat, narrow decorative edges with minimal bulk.
  • Semi-Dry Head technology helps reduce the risk of oil contamination around selected sewing components.
  • DD10 direct-drive servo motor configuration.
  • Differential feed adjustment for fabric control.
  • High-speed capability for professional production environments.
  • Suitable for specialised garment finishing where a narrow rolled hem is required.

Preventive Maintenance

Regular maintenance helps support stitch quality and reliable machine operation. Follow the official JUKI manual for the exact model and subclass.

Daily Care

  • Remove lint from the looper area, knives and feed dogs.
  • Inspect the needle for damage and replace it when necessary.
  • Check thread paths and threading before sewing.
  • Inspect the stitching area for lint buildup or unusual noise.

Routine Servicing

  • Check lubrication according to the manufacturer's instructions.
  • Inspect upper and lower knives for wear or damage.
  • Check the oil filter and other serviceable components where applicable.
  • Use the specified oil and compatible replacement parts.

Lubrication note: The supplied product information specifies JUKI Machine Oil 18 or an ISO VG18 equivalent. Verify the required lubricant and lubrication procedure in the official manual for the exact machine version. Do not assume every part of a semi-dry head uses the same lubrication method.

Common Troubleshooting Guide

Problem Possible Causes Suggested Check
Thread Breaking Incorrect threading, unsuitable tension, damaged thread path or looper. Recheck threading and tension; inspect the needle and thread guides.
Skipped Stitches Bent or worn needle, incorrect needle installation or timing issue. Check the needle type, installation and threading; seek servicing if the issue persists.
Fabric Puckering Incorrect differential feed, thread tension or presser foot pressure. Test adjustments on a fabric offcut before resuming production.
Poor Cutting Performance Worn or damaged knives, lint buildup or incorrect knife adjustment. Clean the cutting area and have damaged or misaligned knives checked.
Oil Stains Possible oil leakage, incorrect lubrication or contamination. Stop and inspect the affected area; check the lubrication procedure and arrange servicing if needed.

Troubleshooting suggestions are general guidance. Switch off the machine before cleaning or inspecting moving parts. Refer to the manufacturer's manual or a qualified technician for adjustments involving timing, knives or internal mechanisms.

Recommended Spare Parts

Needle & Cutting Components

  • Compatible DC × 27 needles
  • Upper knife
  • Lower knife
  • Needle plate

Looper & Service Components

  • Upper looper
  • Lower looper
  • Compatible presser foot
  • Applicable oil filter or service components

Spare parts and accessories are subject to availability and compatibility. Provide the complete model designation, MO-6804AS-0A4-150/DD10K, when enquiring.

Brand JUKI
Model MO-6804AS-0A4-150/DD10K
Machine Type Industrial overlock machine configured for rolled hem applications
Needles 1
Threads 3
Stitch Type 504, as supplied
Maximum Sewing Speed 7,000 stitches per minute (sti/min), as supplied
Overedge Width 1.5 mm, as supplied for this configuration
Stitch Length 0.6–3.8 mm, as supplied
Differential Feed – Gathering 1:2 (maximum 1:4), as supplied
Differential Feed – Stretching 1:0.7 (maximum 1:0.6), as supplied
Needle System DC × 27, as supplied
Needle Bar Stroke 24.5 mm, as supplied
Maximum Presser Foot Lift 7 mm, as supplied
Motor DD10 direct-drive servo motor configuration
Lubrication Semi-dry head technology with lubrication system; confirm the precise system in the model manual
Specified Lubricating Oil JUKI Machine Oil 18 / ISO VG18 equivalent, subject to manual confirmation
Machine Head Weight 27 kg, as supplied

Export Packaging Information

Package Stated Weight Dimensions (L × W × H) Stated Volume
Machine Head 32 kg 480 × 340 × 500 mm 0.081 CBM
Table 18 kg 1,070 × 570 × 40 mm 0.024 CBM
Stand 20 kg 800 × 580 × 140 mm 0.064 CBM
Total 70 kg combined stated weights 4 cartons, as supplied 0.169 CBM combined stated volume

The listed dimensions and CBM values are reproduced from the supplied information. Confirm the final carton count, package weights and freight measurements with the supplier before arranging shipment.

Why Buy from Ban Soon Sewing Machine?

Industrial Sewing Expertise

Discuss your fabric, finishing requirements and production needs with a specialist sewing machine supplier.

Delivery & Installation

Ask about local delivery, machine installation and setup arrangements for your location.

Operator Training

Eligible machine packages may include in-house training at the Clementi showroom.

Technical Support

Get assistance with compatible spare parts, maintenance enquiries and servicing arrangements.

Refer to the manufacturer's catalogue for additional information about the MO-6800A series. Confirm that the documentation covers your exact MO-6804AS subclass and DD10K configuration.

Download JUKI Catalogue (PDF) ↓

Warranty & Ban Soon Care Support

Ban Soon sewing machine training In-House Machine Training

Ask about training and operating guidance available with eligible machine purchases at the Clementi showroom.

 Ban Soon technical consultation Technical Consultation

Get help with product questions and machine operation through the applicable support channels.

 Ban Soon trade-in programme Trade-In Programme

Enquire about trade-in options for eligible existing sewing equipment.

 Ban Soon sewing machine demonstration Product Demonstration

Ask about a machine demonstration and whether your intended fabric can be tested before purchase.

 Ban Soon payment options Payment Options

Contact our team for current payment methods and eligible instalment arrangements.

 Ban Soon warranty and servicing Warranty & Servicing

Confirm the warranty duration, coverage and applicable servicing terms with your quotation.

Warranty and package inclusions: The supplied product information advertises a 1-year warranty, free one-year in-house training, local islandwide delivery, installation and product demonstration. Please confirm eligibility, coverage, exclusions and delivery conditions in the final quotation before purchase.

Enquire About the JUKI MO-6804AS

Looking for a specialised rolled hem machine for chiffon, silk, bridal textiles or lightweight fashion production? Contact Ban Soon to confirm the machine configuration, compatible needles, spare parts, complete set and available support package.
