| Brand |
JUKI |
| Series |
MF-7500 Series |
| Machine Type |
Industrial top and bottom coverstitch machine |
| Stitch Type |
2-needle, 3-needle or 4-needle top and bottom covering stitch, depending on configuration |
| Maximum Sewing Speed |
Up to 5,000 stitches per minute |
| Needle System |
UY128GAS (#10S); compatible sizes stated as #9S–#12S. Confirm needle selection for the exact subclass and fabric. |
| Presser Foot Lift |
5 mm (top and bottom); 8 mm (bottom only), according to the supplied specifications |
| Stitch Pitch Adjustment |
Dial adjustment |
| Differential Feed |
Micro-adjustment mechanism |
| Lubrication |
Automatic lubrication |
| Specified Lubricating Oil |
JUKI Machine Oil 18 (ISO VG18) |
| Needle Bar Stroke |
31 mm (standard); approximately 33 mm for specified heavy-material configurations |
| Power Supply |
Single-phase 100–120 V / 200–240 V or three-phase 200–240 V, subject to the selected motor and configuration |
| Power Consumption |
500 VA with automatic thread trimmer, as stated in the supplied specifications |
| Machine Head Weight |
Approximately 45 kg without device; 53 kg with UT35; 58 kg with UT37 |
Important specification note: The MF-7500 is a series with different subclasses and optional devices. Needle configuration, thread trimming, presser-foot lift, needle-bar stroke, power requirements and included accessories may vary. Please confirm the exact model code, motor, voltage and table configuration with Ban Soon before ordering.
