Dürkopp Adler 967 H-TYPE – Heavy-Duty Single Needle Lockstitch Longarm Sewing Machine

The Dürkopp Adler H-TYPE 967-100382-100 is a high-performance heavy-duty longarm sewing machine engineered for extreme sewing applications involving bulky materials, large workpieces, heavy fabrics, technical textiles, and extremely thick sewing threads.

Developed to meet the demanding requirements of modern industrial sewing, the H-TYPE Class 967 combines robust construction, high penetration force, exceptional sewing dynamics, large material clearance, and advanced automatic functions. Its longarm configuration provides generous workspace for handling large and bulky workpieces with ease.

With features including an XL barrel hook, up to 15 mm stitch length, 30 mm presser foot lift, up to 12 mm alternating foot stroke, automatic thread trimming, automatic backtacking, integrated LED lighting, and a motor-driven bobbin winder, the Dürkopp Adler 967 is designed for demanding professional and industrial production environments.

Key Specifications

• Model: H-TYPE Class 967
• Model / Subclass: 967-100382-100
• Machine Type: Heavy-duty single needle lockstitch longarm machine
• Maximum Stitch Length: 15 mm
• Maximum Presser Foot Lift: 30 mm
• Maximum Alternating Foot Stroke: 12 mm
• Maximum Sewing Speed: 1,000 stitches/min.
• Thread: Extremely thick sewing thread, up to Nm 5/3
• Hook: Extra-large XL barrel shuttle hook
• Clearance: 1,000 mm wide × 225 mm high
• Control System: DAC classic
• Control Panel: OP1000
• Feed System: Bottom feed, needle feed and alternating presser feet

Designed for Extreme Sewing Applications

The Dürkopp Adler 967 H-TYPE is designed for applications where conventional industrial sewing machines may not provide sufficient penetration force, material clearance, stitch length, or thread capacity. Its robust construction and powerful integrated sewing drive allow it to handle demanding heavy-duty sewing operations.

• Exceptional penetration force for heavy and bulky materials.
• Large longarm workspace for oversized workpieces.
• Suitable for extremely thick sewing threads.
• High presser foot lift for feeding bulky material layers.
• Large alternating foot stroke for climbing over different material thicknesses.
• Long stitch length for assembly and decorative seams.

Major Features & Advantages

• Excellent Stitch Quality: Produces consistently tight and precise stitches, even when sewing with extremely thick threads up to Nm 5/3.
• Extra-Large Sewing Clearance: The 1,000 mm wide and 225 mm high clearance provides excellent space for large-area workpieces.
• 15 mm Maximum Stitch Length: Supports long stitches for heavy-duty assembly and decorative seams.
• 30 mm Presser Foot Lift: Makes feeding and removing bulky and thick workpieces easier.
• XL Barrel Hook: Provides approximately 70% greater bobbin capacity compared with a standard hook.
• 12 mm Foot Stroke: Allows the machine to safely sew across material layers with different heights.
• Heavy-Duty Thread Trimmer: Robust thread trimming system designed for extremely thick sewing threads.
• Integrated Sewing Drive: Provides high penetration force and dynamic sewing performance.
• Automatic Functions: Includes automatic thread trimming, seam backtacking, and presser foot lifting.
• Integrated LED Sewing Light: Provides improved visibility around the needle and sewing area.
• Maintenance Indicator: Helps monitor required machine maintenance.

Control & Operating Features

• DAC classic control system.
• OP1000 multifunction control panel.
• Integrated 6-function keypad with ergonomically positioned favourite key.
• Electronic needle positioning using the Jog-Dial.
• Jog-Dial provides functionality similar to an electronic handwheel.
• Control for two different feeding lengths.
• Thread nipper for a neat and secure seam beginning.
• Automatic speed limitation according to foot stroke and feeding length.

Machine Equipment

Applications

The Dürkopp Adler 967 H-TYPE is suitable for demanding industrial sewing applications involving heavy, bulky, and technical materials. Its longarm configuration is particularly useful when large workpieces require additional clearance and workspace.

• Heavy-duty industrial sewing
• Technical textiles
• Large and bulky workpieces
• Heavy fabrics
• Thick material assemblies
• Applications requiring extremely thick sewing thread
• Heavy-duty assembly seams
• Decorative seams on thick materials
